• Myers ME40 Cast Iron 4/10 HP Submersible Effluent Pump - Part Number ME40PC-11-CI

Myers ME40 Cast Iron 4/10 HP Submersible Effluent Pump

Print

65 MAX GPM, 40 FT MAX HEAD, 2" DISCHARGE

The Myers ME40 Cast Iron submersible effluent pump features a rugged fully cast iron design with a non-clog vortex style impeller with solids handling up to 3/4''. Automatic operation is achieved with a wide angle mechanical float switch with a piggyback plug.

CSA

Discontinued

$329.00MSRP: $395.00

Item #:ME40PC-11-CI

Manufacturer: Myers Pumps

SEPTIC SOLUTIONS HAS DISCONTINUED
THIS ITEM FROM OUR INVENTORY

Myers ME40-CI Specifications

  • Model ME40PC-11-CI
  • 4/10HP, 115VAC, 9.7A, 60 Hz
  • 45 GPM @ 15ft of Head Pressure
  • Shut Off: 40ft, Max GPM: 65
  • 2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
  • Vortex Style Impeller
  • Complete Rugged Cast Iron Design
  • Includes 20' Power Cord with Plug
  • Includes 20' Wide Angle Mechanical Float Switch with Piggyback Plug
  • Dimensions: 8.95'' L x 7.31'' W x 12.38'' T
  • One Year Warranty

Myers ME40-CI Series Applications

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. - See more at: http://www.libertypumps.com/Category/effluent-pumps#sthash.s9eLcImw.dpuf

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. These pumps can handle smaller solids up to 3/4’’ in size. These units are normally used to pump discharge from a septic tank or an aerobic system to a drain field, secondary treatment system, or surface discharging point.

  • STEP Systems
  • LPP Systems
  • Mound Systems
  • Liquid Waste Transfer
  • Commercial Sump Applications
  • Effluent and Wastewater Removal

Myers ME40 4/10 HP Submersible Effluent Pump Downloadable Documents

FileName
ME40-BrochureViewDownload
