100 Gallon Simplex Polyethylene Pump Station with 1/2 HP Effluent Pump

100 GALLON POLYETHYLENE TANK

• 28'' Diameter, 57'' Tall
• Heavy Duty Poly Plastic Designed For Direct Burial
• 24'' Diameter Polylok Access Cover
• Risers Available To Bring Access To Grade
• 4'' Inlet Hole with Grommet
• 2'' SCH 40 Discharge Pipe Sealed with Grommet
• Cord Seals For Power and Float

LIBERTY 1/2 HP EFFLUENT PUMP

• Model 283
• 1/2 HP, 115VAC, 8.0A, 60 Hz
• 50 GPM @ 15ft of Head Pressure
• Shut Off: 37ft, Max GPM: 70
• 1-1/2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
• Vortex Style Impeller
• Liberty's One-Piece "Unibody" Casting

• Includes Quick-Disconnect 10' Power Cord with Plug
• Includes 10' Wide Angle Mechanical Float Switch with Piggyback Plug
• Dimensions: 9.5'' L x 6.4'' W x 13.2'' T
• Three Year Warranty

RELATED ITEMS SOLD SEPARATELY

These items are considered optional but are often added to our pump stations:

• Observer 500 High Water Alarm
• SPI BIO-HWAP Economy Simplex Control Panel

• SPI SSC12B Simplex Control Panel
• Check Valve

This item is custom built to our customers' site specific needs. Therefore it is considered a "Custom Product" and cannot be returned for a refund. See our Return Policy for more details.
