SPI Model SDC3B460 Three Phase Duplex Control Panel (460V, 0-10 FLA)

This panel was designed to control and monitor a dual submersible pump system with 3 Phase power at 460V. The overloads that are installed in the panel are based on the customer provided FLA rating of the submersible pump(s). This panel can be adapted to accommodate larger pumps at an additional cost.

THE FLA RATING OF THE SUBMERSIBLE PUMPS MUST BE PROVIDED IN THE ORDER COMMENTS DURING CHECKOUT. THIS SPECIFICATION IS REQUIRED IN ORDER TO BUILD THE CONTROL PANEL.

BUILT TO ORDER IN 2 TO 3 WEEKS

$3100.00MSRP: $3995.00

Item #:50A510

Manufacturer: SPI

Product Features
Product Documents

SSC3B460 Panel Features

460V, Three Phase
Adjustable Overloads Based On Customer Provided FLA of Submersible Pumps
(3) Mechanical Floats w/ 15ft Cords
Circuit Breakers for Pump and Alarm/Control Circuits
360 degree red alarm light, High decible audible buzzer (85 dB)
Automatic Alternating Relay
Pump run light indicator
Pump Hand/Off/Auto heavy duty toggle
Alarm On/Test/Mute heavy duty toggle
Field wiring terminal strips
IEC contactors (2,000,000 cycle rating)
Color Coded Wiring
Dimensions: 17.5'' W x 22.88'' T x 10.68'' D
NEMA 4X Enclosure, UL 508A Listed
Two Year Warranty

SSC3B460 Panel Applications

Works in Both Outdoor and Indoor Applications
Controlling A Dual Submersible Pump Station
Automatic Alternating Relay Alternates Pump Cycles
Monitoring Liquid Levels
Sump and Sewage Basins
Cisterns
Alerts of Submersible Pump Failure
Includes 3 Mechanical Float Switches
NEMA 4X Enclosure
UL 508A Listing
Two Year Limited Warranty

Special ordered items, Items marked "Built To Order", and Custom Products are not returnable. Septic Solutions, Inc. may offer products manufactured or assembled to customers specifications (“Custom Product(s)”). Septic Solutions, Inc. is not responsible for verifying or confirming the accuracy of specifications provided by customer to Septic Solutions, Inc. for Custom Products. All Custom Products are sold on a “FINAL SALE” basis only, and no cancellations, returns, refunds or credits are allowed.
