• Navigator Plus Mechanical Pump Float Switch with 20' Cord, Piggyback Plug - Part Number 20A114

Navigator Plus Mechanical Pump Float Switch with 20' Cord, Piggyback Plug

Print

The Navigator Plus Mechanical float switch is designed to control pump up to 3/4 HP at 120VAC and includes a piggyback plug for easy installation. This float switch is normally open and is activated to "ON" in the raised position.

CSARU

In Stock

$95.00MSRP: $115.00

Item #:20A114

Manufacturer: SPI

Float Clamp / Weight Options:

  • 75 Degree Wide Angle Mechanical Pump Switch
  • Activates at 45 degrees above horizontal, Deactivates at 30 degrees below horizontal
  • 20' Cord with a Piggyback Plug
  • 15 Amp, 14/2 SJOW Wire, 120VAC, Piggyback Plug
  • Controls Pumps Up To 1 HP @ 120V
  • Adjustable Pumping Range of 6 to 36 Inches
  • SST Pipe Mount Assembly Included
  • UL Listed, Heavy Duty Contacts
  • Normally Open Contacts for Emptying Applications
  • Activates To ON In The Raised Position
  • Designed For Use In Sewage and Wastewater Applications
  • Controls Pumps Up To 15 Amps At 120VAC
  • Piggy-Back Plug For Easy Installation
  • Custom Cord Lengths Available, Call 1-877-925-5132
