• Liberty FL50-Series 1/2 HP Submersible Effluent Pump - Part Number FL51A

Liberty FL50-Series 1/2 HP Submersible Effluent Pump

Print

92 MAX GPM, 55 FT MAX HEAD, 1-1/2" or 2'' DISCHARGE

The Liberty FL50-Series Submersible Effluent Pumps provide efficient, low-cost pumping in mid-range head on-site wastewater systems, liquid waste transfer, and commercial sump applications. Built of heavy cast iron with stainless steel fasteners for years of reliable performance. Automatic operation is achieved with a wide angle mechanical float switch with a piggyback plug.

Assembled In USAPowder Coated Tough

In Stock

$806.25MSRP: $1075.00

Item #:FL51A

Manufacturer: Liberty Pumps

Power Cord Length:

Liberty FL50-Series Specifications

  • Model FL51A
  • 1/2 HP, 115VAC, 12.0A, 60 Hz
  • 50 GPM @ 30ft of Head Pressure
  • Shut Off: 55ft, Max GPM: 92
  • 1-1/2'' OR 2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
  • Vortex Impeller Made of High Temp Engineering Polymer Permits Passage of Solids without Clogging
  • Includes Quick-Disconnect 10' Power Cord with Plug
  • Includes 10' Wide Angle Mechanical Float Switch with Piggyback Plug
  • Dimensions: 11.2'' L x 7.0'' W x 12.8'' T
  • Three Year Warranty

Liberty FL50-Series Applications

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. - See more at: http://www.libertypumps.com/Category/effluent-pumps#sthash.s9eLcImw.dpuf

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. These pumps can handle smaller solids up to 3/4’’ in size. These units are normally used to pump discharge from a septic tank or an aerobic system to a drain field, secondary treatment system, or surface discharging point.

  • STEP Systems
  • LPP Systems
  • Mound Systems
  • Liquid Waste Transfer
  • Commercial Sump Applications
  • Effluent and Wastewater Removal

Liberty Submersible Sewage and Effluent Pumps

Liberty FL50-Series 1/2 HP Submersible Effluent Pump Downloadable Documents

FileName
FL50_SpecificationsViewDownload
FL50-FL60-FL70_FeaturesViewDownload
Liberty-InstallationViewDownload
