Liberty FL200-Series 2.0 HP Submersible Effluent Pump

100 MAX GPM, 132 FT MAX HEAD, 2'' DISCHARGE

The Liberty FL200-Series Submersible Effluent Pumps provide efficient, low-cost pumping in high head on-site wastewater systems, liquid waste transfer, and commercial sump applications. Built of heavy cast iron with stainless steel fasteners for years of reliable performance. Automatic operation is achieved with a wide angle mechanical float switch with a piggyback plug.

In Stock

$1383.00MSRP: $1844.00

Item #:FL202A

Manufacturer: Liberty Pumps

Liberty FL200-Series Specifications

Model FL202A
2.0 HP, 208-230VAC, 15.0A, 60 Hz
80 GPM @ 60ft of Head Pressure
Shut Off: 132ft, Max GPM: 100
2'' NPT Vertical Female Discharge, 3/4'' Solids Handling
Vortex Impeller Made of High Temp Engineering Polymer Permits Passage of Solids without Clogging
Includes Quick-Disconnect 25' Power Cord with Plug
Includes 25' Wide Angle Mechanical Float Switch with Piggyback Plug
Dimensions: 11.8'' L x 8.2'' W x 18.3'' T
Three Year Warranty

Liberty FL200-Series Applications

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. - See more at: http://www.libertypumps.com/Category/effluent-pumps#sthash.s9eLcImw.dpuf

An effluent pump is typically used in septic tank applications. Effluent is the gray wastewater that remains after the solids settle out. These pumps can handle smaller solids up to 3/4’’ in size. These units are normally used to pump discharge from a septic tank or an aerobic system to a drain field, secondary treatment system, or surface discharging point.
