Alderon Go2 Duplex Submersible Pump Control Panel (120/230V, 0-20FLA)

Print

The Alderon Go2 Duplex Pump Control is designed to control and monitor pump station with two submersible pumps. The Go2 series panels include pump circuitry for two submersible pumps, built-in high water alarm, and 3 mechanical float switches for "OFF", "LEAD ON", and "LAG/ALARM" controls. A fourth float can be added to separate the "LAG" and "ALARM" functionality.

The Go2 panel utilizes a power relay instead of a motor contactor to turn the submersible pump on and off and includes a Hand/Off/Auto toggle switch for the pump.

Made In USANEMA 4XUL Listed

In Stock

$879.00MSRP: $1210.00

Item #:2010538

Manufacturer: Alderon

Alderon Go2 Duplex Control Panel Features

  • 120/230VAC, Single Phase, 0-20 FLA
  • (3) Mechanical Floats w/ 20ft Cords for OFF, LEAD ON, LAG/ALARM Controls
  • Fourth Float Optional to Separate LAG / ALARM functions
  • Automatically Alternates the Pumps Each Cycle
  • (2) Pump Circuit Breakers, Automatic Resettable Alarm and Control Fuse
  • Two Power Inputs: 120/230V for Pump Power, 120V for Control Power
  • Multi-Color LED Beacon: Green = Normal, Green Flash = Pump Run, Red Flash = High Water
  • High decibel audible buzzer (100 dB)
  • Status LEDs - Pump Run Indicator, Float Activated Indicator
  • Float Out of Sequence Alarm - Automatically Detects a Faulty Float Switch
  • Hand/Off/Auto toggle switch for each pump
  • Alarm On/Test/Mute heavy duty toggle
  • Power Relay (100,000 cycle rating)
  • Auxiliary Dry Contracts - NO/NC
  • Built-In Circuit Board Lightning and Surge Protection
  • Color Coded Wiring, Field Wiring Terminal Strips
  • NEMA 4X Rated Enclosure, UL 508A Listed
  • Three Year Warranty

Alderon Go2 Duplex Control Panel Applications

  • Sewage Pump/Lift Stations with Two Pumps
  • Effluent Pump/Lift Stations with Two Pumps
  • Monitors liquid levels and gives alarm for high water
  • Automatically alternates pumps each cycle
  • LAG ON functionality allows the secondary pump to come on in the event of primary pump failure

Alderon Go2 Duplex Control Panel Downloadable Documents

FileName
Go2 1P Duplex Series Quick Start GuideViewDownload
Go2 1P Duplex Series SpecificationsViewDownload
